Optimize Fiber Expansions with the Y-Block
The Y-Block is a specialized accessory designed for fiber installations, enabling the addition of a second and third fiber cable or duct into existing duct systems. It is an essential tool for network upgrades and expansions, allowing new cables or ducts to be installed without disturbing the existing ones. The Y-Block also features an extra direct air connection, supporting installations when blowing into larger ducts or pipes.
After Blower for V2 duct clamps. Robust handheld fiber blowing unit. Hand powered operation.
Air connection: 3⁄4“ Claw connector
Max pressure: 16 Bar (232 psi)
Cable diameter: 1 – 16 mm
Microduct: 7 – 20 mm
Smooth wall Conduit: 0.75″-2.0″
Weight: approx. 0.5 kg (1.1 pounds)
After Blower for V3 duct clamps. Robust handheld fiber blowing unit. Hand powered operation.
Air connection: 3⁄4“ Claw connector
Max pressure: 16 Bar (232 psi)
Cable diameter: 4 – 40 mm
Microduct: 10 – 20 mm
Smooth wall Conduit: 0.75″-2.0″
Weight: approx. 0.5 kg (1.1 pounds)
Jetting working table for fiber blowing machines.
The stable and robust frame with a stainless top plate makes it easy to position your machine. Foldable for easy transportation.
Rubberized respectively toothed drive wheel for fiber.
Drive belts for different conditions.
Brass cable heads.
Threaded cable heads are available in the sizes: 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10 and 16
Unthreaded (pinched in place) cable heads are available in the sizes: 1.8 and 2.0
Duct lubrication for ducts up to 16/12 mm.
Cleaning & lubrication – AVOID TROUBLE – do it right from the beginning!
You use the lubrication together with cleaning sponges by blowing them through the duct for lubrication AND cleaning. If you do this step carefully, you will avoid worries and gain a lot of time. By looking at the sponge, you can determine if more sponges need to be blown through. The lubricant also reduces static electricity!
Duct lubrication for ducts greater than 16/12 mm.
Cleaning & lubrication – AVOID TROUBLE – do it right from the beginning!
You use the lubrication together with cleaning sponges by blowing them through the duct for lubrication AND cleaning. If you do this step carefully, you will avoid worries and gain a lot of time. By looking at the plug, you can determine if more plugs need to be blown through. The lubricant also reduces static electricity!
Cleaning plugs for duct.
Cleaning & lubricantion – AVOID TROUBLE – do it right from the beginning!
You use the lubrication together with purging plugs by blowing them through cloth or pipe for lubrication AND cleaning. If you do this step carefully, you will avoid worries and gain a lot of time. By looking at the plug, you can determine if more plugs need to be blown through.
Available for all sizes of duct and pipes.
Drum rack for fiber cable drums up to 1200 mm (47.2 inches).
Drum rack for fiber cable drums. Easy assembly and disassembly, few parts. The drum rolls very easily on the drum rack. Improves ergonomics by allowing the drum rack to be turned 180°; this way, you can pull or push the drum in front of you.
Max 1200 mm (47.2 inches) / 150 kg (330 pounds). Adapter for Ø80-60-40 mm (3.15-2.36-1.57 inches).
Transport size: L110 x W120 x H60 in inches
Weight: 10 kg (22 pounds)
Drum rack for fiber cable drums up to 800 mm (31.5 inches).
JetSeal cable seals for Jetting V0 (16 mm), V2, and V3 are made from high-performance TPU 90Sha, offering durability, flexibility, and resistance to wear, chemicals, and temperature variations. Color-coded for easy selection.
Tools for cutting duct 90 degrees
Tools for cutting duct 90 degrees in order to avoid stops in duct connectors
Micro Duct Cutter for ducts upp to 16mm. Art.no MDC-16.
Duct Cutter for ducts up to 42mm. Art.no PC-42. Spare blades for PC-42. Art.no PCB-42.
Tool for cutting pipe 90 degrees
Professional tool for clean 90 degree cutting, of Duct/ Pipe 90 up to 63 mm.
